Volkswagen digital cluster retrofit by model
From the Golf MK5 to the current Caddy: digital clusters matched to PQ and MQB platform cars across the VW Group range.
Installed
Volkswagen fitment table
30 fitment groups covering the full range. Confirm the factory system before ordering.
| Model | Years | Panel | Platform | Fitment type |
|---|---|---|---|---|
| Golf MK6 / Sharan | Golf 6 2009-2014, Sharan 2012-2019 | 10.25" | PQ | Shared cluster body. Sharan needs slight trimming of two housing corners. GTI and R included |
| Passat B6 / B7 / CC | 2005-2016 | 10.25" | PQ | B6 needs either a B7 bezel or the dedicated harness. Estate, Alltrack and R-Line included |
| Tiguan | 2009-2017 | 12.3" | PQ | Direct swap, no cutting |
| Passat NMS (US / China) | 2011-2022 | 12.3" | PQ | Covers TDI, Sport, R-Line, BlueMotion and Limited Edition |
| Passat (China) | 2016-2017 | 12.3" | PQ | All trims |
| Eos / Scirocco / Sagitar MK5 | Eos 2005-2015, Scirocco 2009-2016, Sagitar 2006-2014 | 10.25" | PQ | Shared housing and connectors. 2005-2008 red-screen cars need a dedicated harness |
| Jetta / Sagitar MK6 | 2011-2014 | 10.25" | PQ | GLI included |
| Jetta / Sagitar MK6.5 | 2011-2018 | 10.25" | PQ | SportWagen, GLI, TDI and Hybrid included |
| Golf MK7 / MK7.5 | 2013-2020 | 12.3" | MQB | Piano black or pearl grey bezel. GTI, R, Cabriolet and Alltrack included |
| Passat B8 / Magotan B8 / CC / Arteon | 2015-2023 | 12.3" | MQB | LHD and RHD specific - confirm steering side when ordering |
| Amarok | 2010-2020 | 12.3" | MQB | Factory analogue cluster only |
| T-Roc | 2018-2022 | 12.3" | MQB | Factory analogue cluster only |
| Phideon | 2016-2021 | 12.3" | MQB | Factory analogue cluster only |
| Jetta / Sagitar | 2018-2024 | 12.3" | MQB | Factory analogue cluster only |
| Skoda Octavia | 2016-2022 | 12.3" | MQB | Factory analogue cluster only |
| Skoda Superb | 2013-2015 | 12.3" | PQ | Factory analogue cluster only |
| Skoda Superb | 2016-2019 | 12.3" | MQB | Factory analogue cluster only |
| Golf MK5 / Jetta MK5 / Tiguan (early) | 2006-2011 | 10.25" | PQ | Requires the 36-pin black connector |
| Polo | 2009-2018 | 10.25" | PQ | Imported 2009-2016, China-built 2012-2018 |
| Polo / Tacqua | 2019-2021 | 10.25" | MQB | Factory analogue cluster only |
| Tayron | 2019-2022 | 12.3" | MQB | Factory analogue cluster only |
| Lamando | 2015-2018 | 12.3" | MQB | Factory analogue cluster only |
| Lavida / Gran Lavida / Lavida Classic | 2013-2019 | 12.3" | PQ | China-market models |
| SEAT Leon | 2013-2018 | 12.3" | MQB | Factory analogue cluster only |
| Caddy | 2008-2025 | 12.3" | MQB | 2008-2010: 36-pin connector. 2011-2019: small connector |
| Multivan / Caravelle T5 | 2013-2015 | 12.3" | PQ | Factory analogue cluster only |
| Multivan / Caravelle T6 | 2015-2019 | 12.3" | PQ | Factory analogue cluster only |
| Tiguan L | 2017-2022 | 12.3" | PQ | Factory analogue cluster only |
| Bora | 2013-2015 | 12.3" | PQ | Factory analogue cluster only |
| Touran | 2011-2015 | 10.25" | PQ | Factory analogue cluster only |
Notes for installers
Volkswagen fitment follows the platform, not the badge - the same kit covers VW, Skoda, SEAT and Jetta models built on the same floorpan. Two rules apply almost everywhere: the car must have left the factory with an analogue (mechanical) cluster, and the original cluster housing is reused, so no cutting or extra parts are needed. Two exceptions are worth flagging to your customers - the Passat B8 family is LHD or RHD specific, and the early Golf MK5, Jetta MK5 and Caddy 2008-2010 need the 36-pin black connector. Panels are 10.25 inch on PQ and 12.3 inch on MQB.
